This servo press is suitable for application in auto parts, consumable electronics and household appliances which can reach perfect forming performance. By combining the progressive die with pendulum curve, productivity can possibly be doubled, which saves over 50% of energy. Furthermore, automated transfer production line can also be added to upgrade the productivity.
Features
More flexibility in applications with different operating modes.
Suitable for high tensile strength steel product.
Better forming capabilities.
Saving energy and environmental friendly.
Perform secondary operations in-die (drilling, tapping, staking).
Better integration with work cells and automation.
Review the specifications of our EC1 Series H frame highs speed press below, and then contact us for assistance in identifying the right mechanical press for your application.
Technical Datas
| Model | EC1-25 | EC1-35 | EC1-45 | EC1-60 | EC1-80 | EC1-110 | EC1-125 | EC1-160 | EC1-200 | EC1-250 | EC1-315 | ||
| Nominal Pressure | kN | 250 | 350 | 450 | 600 | 800 | 1100 | 1250 | 1600 | 2000 | 2500 | 3150 | |
| Nominal Pressure Stroke | mm | 1.5 | 2 | 3 | 4 | 5 | 5 | 5 | 6 | 6 | 6 | 6 | |
| Stroke of Slide | mm | 70 | 80 | 100 | 120 | 150 | 180 | 180 | 180 | 200 | 220 | 250 | |
| Speed | SPM | 1-120 | 1-100 | 1-90 | 1-70 | 1-60 | 1-55 | 1-50 | 1-45 | 1-40 | 1-40 | 1-35 | |
| Max Die Height | mm | 200 | 235 | 265 | 310 | 340 | 360 | 360 | 420 | 460 | 500 | 500 | |
| Die Height Adjustment | mm | 50 | 55 | 60 | 70 | 80 | 80 | 80 | 100 | 110 | 120 | 120 | |
| Slide Area | L-R | mm | 680 | 800 | 850 | 900 | 1000 | 1150 | 1150 | 1250 | 1400 | 1500 | 1500 |
| F-B | 300 | 400 | 450 | 500 | 550 | 600 | 600 | 800 | 820 | 850 | 850 | ||
| Bolster Area | L-R | mm | 300 | 350 | 400 | 500 | 550 | 650 | 650 | 700 | 850 | 950 | 950 |
| F-B | 230 | 250 | 300 | 400 | 450 | 500 | 500 | 550 | 650 | 700 | 700 | ||
| Air Pressure | Mpa | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | |
| Motor Mode | Air Cooling | Air Cooling | Air Cooling | Air Cooling | Air Cooling | Water Cooling | Water Cooling | Water Cooling | Water Cooling | Water Cooling | Water Cooling | ||
| Motor Driver No. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
