From June 04-06, Goanwin is attending exhibition in Shenzhen, China. In this exhibition, there are 3 types of our machines shown to customers. They are C-Frame single crank servo press EC1-110, knuckle joint high speed press GT-80 and CNC maching center VCE-855.
C-Frame single crank servo press EC1-110
Features:
◆ The ability to set and change the speed of the process at will makes production ease of use unrivaled.
◆ Compared with conventional presses, productivity can be significantly increased by speeding up the return stroke.
◆ Stroke height and motion sequence can be programmed, resulting in production flexibility.
◆ Motion sequences can be optimized to improve and extend part quality and die life.
◆ Efficient drive solutions reduce energy consumption.
◆ Fewer mechanical parts and easier maintenance than conventional presses.
◆ Equipped with a handwheel fine-tuning function that significantly reduces mold trial time.
Knuckle joint high speed press GT-80
Features:
◆ The press adopts an elbow joint linkage mechanism to minimize thermal displacement, chip runout, and fine pressing effect, making it the most suitable standard model for high-speed precision machining with high reliability.
Highly reliable standard model
◆ Wide range series, high speed model.
◆ This elbow joint type press maximizes the characteristics of the elbow joint mechanism, featuring a simple mechanism, large capacity, high rigidity, and good thermal balance.
◆ Equipped with a fully counterbalance to minimize the height displacement of the closed die due to SPM change and the lower dead center displacement of the first and second presses.
◆ Adoption of counterbalance mechanism with left and right forces canceling each other, double-piston 8-face needle roller guideway and double guideway further improves the eccentric loading capacity of the slide.
◆ Equipped with new backlash-free clutch/brake with high life and low noise for quieter operation.
CNC maching center VCE-855
Features:
◆ The latest vertical machining center machine of VCE series is equipped with the improvements required by owners and operators. The latest control system has a simple interface and powerful functions, intelligent control interface, diversified functions, easy to operate multi-touch screen, and faster speed and higher machining accuracy.
◆ The design method of FEM (Finite Element Analysis System) simulation and optimization is adopted to fully optimize the overall rigidity of the machine tool and improve the dynamic performance of the machine tool.
◆ The structural parts of the machine are all made of high-quality resin sand molding, high-strength cast iron casting and annealed twice to ensure the high rigidity and stability of the structure.
